25 MPO Single Mode Fiber Optical Coupler Key Up/Down 8/12/24 Core Adapter

Description

• Main ParametersGreen type simplex MPO Coupler with screw mounting wing, suitable for 8/12/24 core MPO fiber optic cable, key up to key down connection, -40~75 Operating temperature,
• Easy to distinguishThe green MPO coupler can be used for both single mode and multimode fiber patch cord, but the green type coupler is recommended for single mode MPO patch cord connection, which can be better distinguished
• Effective IsolationThe coupler can effectively isolate the signal field from the main control end, prevent accidental damage of the main control system, and effectively inhibit the noise of the ground circuit
• Stable PerformanceLow insertion loss, typical value 0.50dB, maximum value 0.7dB, which can reduce equipment loss
• High InterchangeabilityThe Coupler has good interchangeability (0.20db) and repeatability (0.20db), which can be plugged more than 500 times

Product Description
MPO adapter primarily relies on its own guide grooves and the keys on the MPO fiber connectors to determine the fiber docking sequence. It is locked in the adapter by aligning the guide holes on the female connector with the guide pins on the male connector.

Coupler Specifications
Product Type: MPO coupler with screw mounting wing
Cable type: MPO single mode/multimode fiber patch cord
Coupler colorgreen
Insertion Loss: 0.5dB
High Interchangeability: 0.2db
High Repeatability: 0.2db
Operating Temperature: -40~75
Packing Quantity:25 PCS
