Description
- -Support 4 channels realtime video display with multiple display modes.
- -Support digital zoom in/out.
- -Support auto sequential switching. Support 4 channels audio input and 1 channel audio output.
- -Support multiple video channels freezing at the same time.
- -Support motion detection alarm, video loss alarm. Note: this video quad supports ana-log cctv security cameras ONLY, doesn't support AHD or IP cameras.
Key Features:
-Support 4 channels real-time video display, each channel can be renamed.
-Support 4 channels audio input, 1 channel audio output and 2 channels video output.
-Support auto sequential switching.
-Support 1, 2, 3, 4 channels or PIP (Picture-in-Picture) multiple video display modes.
-Each PIP position is adjustable.
-Support digital zoom in/out, zooming area is selectable.
-Support multiple video channels freezing at the same time.
-Support motion detection alarm, detective area and alarm duration are adjustable.
-Support video loss detection and alarm.
-Support IR Remote Control.
Parameters:
Video System: NTSC/PAL
Video Resolution: PAL: 720576; NTSC: 720480
Video Frame Rate: PAL: 100fps, NTSC:120fps
Video Input : 4xBNC 1Vp-p,75
Video Output: 1 channel main monitor output, 1Vp-p,75, 1 channel slave monitor output, 1Vp-p,75
Audio Input: 4xRCA
Audio Output: 1xRCA
Auto Switch Intervals: 0~99 seconds selectable
Event Record: 60 groups in max
Alarm Output: None
OSD Language: English
Customized Menu: Brightness ,Contrast, Saturation, Hue, Sharpness can be adjustable
Power Consumption: 4.5W (350mA)
Power Supply: DC 12V, 1A
Operation Temperature: -10~ +60
Product Weight: 1kg
Product Size: 210mm130mm40mm
Note: this video quad supports ana-log cctv security cameras ONLY, doesn't support AHD or IP cameras.
