Description
- POWER SUPPLY: Class D vehicle audio amplifier, Total Power 14,4 @ 1 Ohms: 9500 WRMS, Total Power 14,4 @ 2 Ohms: 7400 WRMS, Total Power 12,6 @ 1 Ohms: 8000 WRMS, Total Power 12,6 @ 2 Ohms: 6100 WRMS, Efficiency @ 2 Ohms: 83%, Efficiency @ 1 Ohms: 73%
- MONO BASS AMPLIFIER INDICATORS: Blue LED: source and powered amplifier indicator, Red LED: output distortion (clipping), Constant - output short circuit indicator, Yellow LED: low voltage battery, Constant - Fuse blown or missing
- POWER OUTPUT AND IMPEDANCE: Input Voltage: 9 to 15V, Input Impedance: 22K Ohms, THD + Noise: less than 1%, Input Sensitivity: 160mV 600mV, Signal to Noise Ratio: 80dB
- SOUND SPECIALIZATION: This high-powered Power Amplifier is cutting edge technology at its finest. RCA connectors ensure a secure connection between amplifier and speakers that allow distortion-free sound
- OTHER TECHNICAL SPECS: Recommended Fuse: 400A, Current at Rest: 4,5A, Ave. Current Draw (Sinusoidal): 920A, Ave Current Draw (Music): 400A, Power Wire Gauge: 50mm/0 AWG, Speaker Wire Gauge: 2 x 6mm / 2 x 3 AWG, Size: 2.4 x 10.6 x 17.7
Awesome sound quality
