Description
- Optical Fiber End Face Detector Magnification 400X, Recognition accuracy<1m, FC / ST Supporting UPC, SC/LC male and SC / LC female, SC supporting APC Male and female.
- Measurement information recording: Real-time video recording and expansion TF card, convenient and fast recording measurement information. Support data playback, convenient inspection and data statistics.
- Large screen view: 3.5-inch high- definition LCD display is used to further enhance display brightness and clarity. Thereby avoiding visual fatigue and making work easy and simple.
- 80 degree rotating metal bracke: The angle of the bracket can be rotated and adjusted at will, which is stable and convenient. Ergonomic perspective, no need to hold a separate screen to watch.
- Product includes: Tool kit, host, hanging rope, accessory box, use data line, card reader, transfer head
Product Description
this is a handheld optical fiber end-face detector launched by our company. It supports the use of OTDR with USB. With its high-end optical devices and high-resolution cameras, it can Quickly manually focus and detect scratches, dirt, and dust on the fiber end face. Applicable to various scenarios.
400 times magnification, the fiber end face is clearly visible
Less than 1m resolution, clear imaging.
USB Port compatible with the PCs and Laptops(Windows), OTDR( Komshine)
Applicable for UPC: SC/FC/ ST/LC/ SC Female/LC Female(Included)
Applicable for APC: SC/SC Female(Optional)
Quick focus manually.
Light weight and portable, simple operation.
Product Configuration
Type KIP-600P probe
Magnication 400X
Focusing method Manual
Connectors Applicable for UPC: SC/FC/ ST/LC/ SC Female/LC Female(Included)
Connectors Applicable for APC: SC/SC Female(Optional)
Video signal format NTSC/PAL
