Description
- Product Features8 Channels Video data converter compatible for PAL, NTSC, SECAM Video format, Default ship singlemode version (0~20KM), Optional Multimode version(0~500Meters), Leave message to us if need Wavelength: Single-mode 1310/1550m (9/125m), Multimode 850m (50/125m), 1310m (62.5/125m), MTBF (Mean time between failure) over 100,000 Hours.
- Simply Plug & Play just plug in the power cord, connect the BNC 75-5 or 75-3 coaxial cable directly to the device, Easy setup with no configuration or no software needed PD DETECTION: Support Video/PCM/AHD/HD-CVI/TVI/1080P Detection function, automatically detect devices.
- Durable Metal HousingEvery GESD Video Data Fiber Optic Media Converter is rigorously tested for reliability, quality, and performance Compact, Lightweight Design:Desktop or wall-mount fanless design ensures quiet operation in small offices and higher reliability over time.
- Lightning Protection 6KVVideo Audio data converter have professional lightning protection design-up 6KV port and power supply thunder prevents, with two levels of protection design respectively, effectively restrain the power of lightning from cable, which equivalent to give the entire CCTV Cameras monitoring system with a security fence.
- 100% Satisfaction Guarantee30-day Money-Back Guarantee with 1 Year Warranty, Lifetime Tech Support and hardware warranty, Free firmware upgrade support and free technical support for long-term assurance.
Package Contents
1 Pair optical device 8CH Video
2 x Power Adapter (supply AC 100-240V universal, DC 12V output)
1 x User Manual singlemode version
Specifications
1. 8 channel Video Data Fiber Optic Media Converter, Video Bandwidth 8MHz
2. Video format compatible PAL, NTSC, SECAM, 15MHZ high-speed sampling
3. Video voltage 1VP-P, Video SNR 70dB Video Input / Output Impedance:75ohm ( unbalanced )
4. Video Interface: BNC, Differential gain 0.7%, Differential phase 0.7
5. Operating temperature: -40 +70 degree, 8- bit linear PCM coding
6. Operating humidity:0-95 % non-condensing
Durable Metal Housing
Compact design, sturdy metal case makes it safe to use in various environments.
The usual time between failures (MTBF) greater than 100,000 hours
Optical Attribute
1. Optical Interface: FC
2. Transmission distance : single-mode fiber :0-20KM, multimode fiber :0-0.5KM(optional version)
3. Wavelength: Single-mode 1310/1550m (9/125m), Multimode 850m (50/125m), 1310m (62.5/125m)
Fanless Design
Built to high heat tolerances, Bilateral heat dissipation, keeps stable and quiet.
For the Environment
1. Video monitoring Security Systems
2. Train/High speed road monitoring,Building control systems
3. Intelligent Traffic Monitoring System (ITS), Radio and television transmission
4. Remote multimedia teaching / campus monitoring
5. Long-distance radio and television transmission system
Lightning Protection 6KV
Video Audio data converter have professional lightning protection design-up 6KV port and power supply thunder prevents, with two levels of protection design respectively, effectively restrain the power of lightning from cable, which equivalent to give the entire CCTV Cameras monitoring system with a security fence.
