Honeywell 747F Flush Mount Indoor Self Contained Siren, 95dB Output at 12 Volts DC, 2 Tones (Steady and Warble), High Quality Mylar Cone, Heavy Duty Magnet, Durable ABS Plastic, Hardware Included

• 95dB output at 12 volts DC
• 2 tones - steady and warble
• High quality mylar cone, Heavy duty magnet
• Durable ABS plastic, Attractive designer case
• Flush mount, Hardware included

Honeywell 747F Flush Mount Indoor Self Contained Siren, 95dB Output at 12 Volts DC, 2 Tones (Steady and Warble), High Quality Mylar Cone, Heavy Duty Magnet, Durable ABS Plastic, Hardware Included

The Honeywell 747F is a flush mounted self-contained indoor siren. The 747F can connect to a hardwired security system without the need for an additional siren driver, as all components necessary are included within the siren housing itself. The 747F produces 95dB of sound on a standard 12V alarm bell circuit.

Key Features
- 95dB output at 12 volts DC
- 2 tones - steady and warble
- High quality mylar cone
- Heavy duty magnet
- Durable ABS plastic
- Attractive designer case
- Flush mount
- Hardware included

Specifications
- Voice coil impedance: 8 ohm
- Voice coil diameter: .79" (20mm)
- Cone diameter: 3.43" (87mm)
- Speaker Type: Mylar cone
- Input Voltage: 6-15VDC
- dB Output: 95dB @ 12VDC @ 10'
- Current Draw: 400mA @ 12VDC 8 ohm load
- Operating Temp: 0C to 50C
- Tone Frequency: Steady - 1200HZ / Warble - 800HZ to 1200HZ, 1 second ramp cycle
- Magnet Weight: 2.8 oz (81g)
- Dimensions: 5" x 6.75" x 1.675" (127mm x 159mm x 42.5mm)
