Low Pass Filter LPF (100MHz)

Description

• Low Pass Filter LPF

LPF-1MK:1MHz LC LPF,DC-1M,insert lost 1M-1.2dB,2M-48dB,3M-80dB
LPF-5MK:5M LC LPF,DC-5M.insert lost 5M-2.7dB,10M-50dB,15M-78dB
LPF-10MK:10M LC LPF,DC-10M,insert lost 10M-1.8dB,20M-49dB,30M-65dB
LPF-30MK,30M LC LPF,DC-30M,insert lost 30M-1.3dB,60M-50dB,90M-67dB
LPF-40MK,40M LC LPF,DC-40M,insert lost 40M-1.8dB,80M-58dB,120M-65dB
LPF-50MK,50M LC LPF,DC-50M,insert lost 50M-1.4dB,100M-53dB,150M-65dB
LPF-100MK,100M LC LPF,insert lost 100M-1.5dB,200M-55dB,300M-55dB
LPF-500MK,500M LC LPF,insert lost 500M-1.1dB,1G-60dB,1.5G-60DB
LPF-1GK,1G LC LPF,insert lost 1G-1.1dB,2G-49dB,3G-60DB
input/output Impedance50 OHM
interface: SMA femalePlate with nickel or gold
size:L*W*H=62*25*12mm
weight:30g
