Description
Camera Image Sensor 1/1.8" Progressive Scan CMOS Min. Illumination 0.0014 @ F1.0 (1/30 s, AGC ON), 0.002 @ F1.2 (1/30 s, AGC ON), 0 Lux with LED on Shutter Speed 1/3 s to 1/100,000 s Slow Shutter Yes Focal length 4 mm Focus Fixed Aperture F1.0 FOV 2.8 mm, horizontal FOV: 102, vertical FOV: 51, diagonal FOV: 125 Lens Mount M16 Auto-Iris No DNR 3D DNR Wide Dynamic Range 120dB 3-Axis Adjustment Pan: 0 to 355, tilt: 0 to 75, rotate: 0 to 355 Compression Standard Video Compression Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264 H.264 Type Baseline Profile/Main Profile/High Profile H.264+ Main stream supports H.265 Type Main Profile H.265+ Main stream supports Video Bit Rate 32 Kbps to 8 Mbps Image Max. Resolution 2560 1440 Main Stream 50Hz: 25fps (2560 1440, 1920 1080, 1280 720) 60Hz: 24fps (2560 1440), 30fps (2304 1296, 1920 1080, 1280 720) Sub Stream 50Hz: 25fps (640 480, 640 360, 320 240) 60Hz: 30fps (640 480, 640 360, 320 240) Third stream 50Hz: 1fps (1280 720, 640 480, 640 360, 352 288, 320 240) 60Hz: 1fps (1280 720, 640 480, 640 360, 352 288, 320 240) Image Enhancement BLC/3D DNR/HLC/Defog Image Settings Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser ROI (Region of Interest) No Network Network Storage Support micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR Alarm Trigger Motion detection, video tampering detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour General Function One-key reset, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter API ONVIF (PROFILE S, PROFILE G), ISAPI
