Description
- Compressor Displacement:1.9cc, Start-up Voltage: 35 V, Rated Voltage:48 V, Voltage Range:35 V - 58 V, Temperature Range:18 ~ 40 degree, Rated Current:1~ 4.1 A (10%), Max Current:7.5 A, Cooling Capacity: 100W ~ 455 W (10%), Max Power Input: 186 W
- High-efficiency components for superior performance,low vibration with anti-vibration cushion.
- Similar to the traditional air conditioner, Is available as an outdoor or indoor unit because of its lightest weight and smallest size.Super small volume: 13.3*8.2*5.7 inch,Super light weight: 5.0kgs (11.02lbs).
- Suitable for small & confined space cooling, such as cabins, cuddy cabins, EV (eletric vehicle), helicopter, cab,compact off-road camper,carriage cooling for trucks and other specialized vehicles such as excavation vehicles and agricultural vehicles,etc.
- High-temperature working condition, which can powered by battery, grid, car power and solar power.
Compressor Type: Rotary DC Inverter Motor
Compressor Displacement:1.9cc
Start-up Voltage: 35 V
Rated Voltage:48 V
Voltage Range:35 V - 58 V
Temperature Range:18 ~ 40 degree
Rated Current:1~ 4.1 A (10%)
Max Current:7.5 A
Cooling Capacity: 100W ~ 455 W (10%)
Max Power Input: 186 W
Condenser:Micro-channel 126*240*16mm
Fan of Condenser:Centrifugal fan 75.5/27.8 CFM
Evaporator:Fin Type 138*125*34mm
Throttle Valve:Capillary 2.0
Operating Ambient Temperature:5 55
Motor Speed:2000 ~ 6000rpm
Driver Board:Variable Frequency Controller
Noise Level:48dB(A)
Compressor protection:Controller Auto-Protecting
Applications:
Small Space Cooling;
Compact Air Conditioning;
Portable & compact cycle cooling;
DC air conditioning system uses our vapor compression technology to chill the air within an enclosed environment.
The air removes the heat from room and provides circulating chilled air without need to change user's existing system architecture.
