Description
- PICkit 5 In-Circuit Debugger/Programmer, Programmer-to-Go support, Type-C port, Supports MPLAB, Card Programmer (PICkit4 DISCONTINUED)
- Connects to computer via a USB Type-C cable. Powered through USB cable or target and can optionally power target (up to 150 mA). Supports powering from the target board (2.7V~5.5V)
- Onboard 8pin SIL programming connector, supports ICSP, JTAG, SWD, UART VCP. Programs devices using MPLAB X IDE or MPLAB IPE. Supports Programmer-To-Go (PTG) to field program devices
- Supports MPLAB PTG iOS/Android app used to select and manage PTG program images via Bluetooth. Supports Virtual Comm Port (VCOM). Supports multiple hardware and software breakpoints, allows setting stopwatch and monitoring variables and internal file registers. Supports debugging in real-time and at full device operational speed
- Supports new devices and features through new/updated packs in MPLAB X IDE or MPLAB IPE. Indicates debugger status via indicator light strip. CE and RoHS compliant
- Compared to the PICkit 4, it can be used stand-alone with the MPLAB Programmer-to-Go (PTG) mobile app, allowing you to connect to the tool from your smartphone via Bluetooth for easier and more flexible visual offline programming operations. It is capable of providing up to 150mA to the target board via the onboard USB Type-C port.
- Supports Programmer-to-Go (PTG), with an additional MicroSDHC card slot and the ability to be self-powered from the target means you can take your code with you and program on the go, and never worry about the code size.
Description
PICkit 5 In-Circuit Debugger/Programmer, Programmer-to-Go support, Type-C port, Supports MPLAB, Card Programmer
Package Contains
PICkit 5 x1
For more user guide resources you may need, pls contact me via Amazon message, i will send you then via attachment.
