Description
- Perfect Vision Solid Copper Conductor. 3Ghz Swept
- On EnviroReel system
- Direct TV and Dish Network approved coaxial cable. Satellite/Dish
- Length 1000FT
- Color Black
DirecTV EnviroReel CR04BSR0-05 Black 1000ft RG6 Solid Copper Coaxial Cable 17AWG ground. This black, single, RG-6 coaxial cable has a solid copper center conductor wire. It is swept tested to 3 GHz, 100% shielded and it has footage markers every two feet for easy length cuts. Ground wire included. UL Listed and SBCA compliant. DIRECTV approved. Packaging: 1,000' EnviroReel Reel. Coaxial Cable Manufacturers Specifications PV part number: CR04BSRO-05 EnviroReel Dispenser is Required. Part Number: ENVIROREEL-KIT Features Coax Type:RG6 with Ground Packaging: EnviroReel ReelE341555Applications:Indoor and Outdoor Use Operating Temperature:-400 C through +75 C(a)Jacket: Nominal OD:6.86 0.15mm Material: PVC Color: Black, White(b) Braids: Material: Aluminum Magnesium Alloy Braid Wire Count: Braid Coverage:80Foil Shield: Material: Adhesive: Aluminum Foil Foil Shield Coverage:100% (18% overlap minimum)(d)Dielectric: Material: Gas Injected Foam PE Nominal OD4.57 mm 0.1 Ohm Conductor: Material: Solid Copper Nominal OD.02mm 0.01 mm (18 ga)(f)Ground: Material: Copper-Clad Steel Nominal OD.15 0.01 mm (17 ga) Impedance: 75 Ohms 3 Ohms Capacitance: 16.2 PF/ft 1 .0 PF/ft Velocity of Propagation: Nominal Delay: 1 .22 NS/ft Conductor DC Resistance: 22 Ohms / Km Shield DC Resistance: 43 Ohms / Km Swept Tested: 5 MHZ-3000 MHz
