Pulse Counter Relay Module, 0.01s Accuracy 1 Channel Easy to Install 0.1S to 9.9s PCB Multifunctional Pulse Counter Relay Board for Industry (12V)

Description

• Main Function: This board can achieve delay time 0.1S to 9.9 s, step size 0.1S, and accuracy 0.01S.
• Ideal Replacement: Adopts advanced technology and quality, a replacement for your old or broken battery board.
• 3 Statuses: There are 3 statuses can be set for this board, working status, power saving status, setting status.
• Easy to Install: Comes with a compact size and a light weight as well, the easy installation can be quickly completed.
• 12 Working Modes: F00F05, F10F15 a total of 12 working modes, there are 8 working modes to set the number of cycles.

1. Main Function: This board can achieve delay time 0.1S to 9.9 s, step size 0.1S, and accuracy 0.01S.
2. 12 Working Modes: F00F05, F10F15 a total of 12 working modes, there are 8 working modes to set the number of cycles.
3. 3 Statuses: There are 3 statuses can be set for this board, working status, power saving status, setting status.
4. Easy to Install: Comes with a compact size and a light weight as well, the easy installation can be quickly completed.
5. Ideal Replacement: Adopts advanced technology and quality, a replacement for your old or broken battery board.

Specification:
Item Type: Control Board
Material: PCB
Working Current:
Digital Tube OFF (Power Saving State): Relay OFF 6MA, Relay ON 35MA
Digital Tube ON (Working State): Relay OFF 29MA, Relay ON 56MA
Three States: Working State, Power Saving State, Setting State
Input Port: Optocoupler isolation input, compatible with NPN, PNP input (5-24V switch )
Output port: 10A relay NO COM NC three ports
There are three wiring methods for the input terminal:
1 No external source required
2 with NPN source
3 with PNP source
Working status: power on working status, F00-F05 mode displays the remaining time, F10-F15 mode displays the remaining time and pulse count value.
Note: When the remaining time is greater than four digits, short press the OK key to scroll and display the remaining time once.
Setting status: short press ''SET'' key to enter setting status, then short press ''SET'' to switch parameters, short press ''++'', ''--'' to modify parameters. Short press the OK key to save the parameters and exit the setting state.
Note: After setting the parameters, it must be powered on again.
Query status: without modifying the parameter setting status, short press the SET button to enter the query status, then press SET to switch parameters, and short press the OK button to
