QIJIE LED Strip Connector Terminal 3 Pin 10mm Non-Waterproof IP20 for Dimmable, Dual Color, WS2812,WS2811 Digital Tape Light,Connect Strip to Extension Wire of 22~20 Gauge,Pack of 10

Description

• One end for strip light and another end for extension wire, DIY a lead connector wire with any length.Applicable for IP20 strip light (3 solder pad) in different LED density ranging 30~120 LEDs per meter.
• No need stripping wire insulation before connection (pierce-to-contact) , easily connect your led strip to cable, power, dimmer or controller without any soldering.
• Clear Cap that will not mask light of first LED thus hardly see dark area in your lighting space. Make lighting effect more uniform.
• Powerful with as much as total 5A current supported, allow you to connect longer LED strip by one connector,reducing cost and connection work.
• With fixing bar on cap and piercing contact design, connector can grip strip light tightly,never worry strip light or wire moving out of connector. Even workable to strip light with 3M VHB red foam adhesive tape.

A 3 pin solderless flexible strip light connector designed to link non-waterproof IP20 strip light to 3 conductor extension wire. No need stripping wire insulation with IPC (insulation-piercing contact) technology. Determine wire gauge and length as you want in linear lighting project with this connector. Powerful,reliable,safe and easy to use.Free you from difficult and dangerous soldering iron operation.
1)LED Strip Type It Can Work With Normal Non-waterproof Dimmable LED strip like SMD3528,SMD2835,SMD5050,SMD5630 and SMD3014,etc. Digital chasing LED strip like WS2811,WS2812 and WS2812B,1903,SK6812,etc. Other IP20 LED tape light 10mm with 3 solder pad.
SPECIAL NOTE: If your LED strip light is waterproof by PURE SILICON coating ,this connector can still work without stripping silicon coating.
2)Package Include
LED Strip Connector 3 Pin:10 PCS
Kindly Note: this package does not include any wire, you can search B01L3FIITU to purchase the wire that can perfectly work with this connector.
3)Tools Needed
A pliers
A scissor will make work more efficient. (cut wire and strip light )
4)Technical Data
Working Voltage:Below 24V
Max Current of Pin: 5A
Pin Quantity: 3 pin
Workable Wire Gauge: 22~20AWG / 0.34~0.54 mm
Workable Strip Light Width: 10mm
Workable PCB Thickness:0.2~0.35 mm
Working Ambient TEMP.: -20~50
Heat Resistance:105
Connector Dimension: 24.3*14.6*7.7 mm
