Description
- Transmit an HDMI source to up to eight different HDMI displays
- Supports up to 4K resolution and 3D video
- Individual status LEDs for each HDMI output
- EDID Management settings
- One (1) 5VDC Power supply included
Seco-Larm MVD-AH18-01Q HDMI 4K Splitter, Transmit an HDMI Source to Up to Eight Different HDMI Displays, Supports Up to 4K Resolution and 3D Video, EDID Management Settings, Includes 5VDC Power Supply
This HDMI Splitter allows for one HDMI source to simultaneously transmit to up to eight different monitors. Supports up to 1080p and 3D video. Key Features Transmit an HDMI source to up to eight different HDMI displays Supports up to 4K resolution and 3D video Individual status LEDs for each HDMI output EDID Management settings One (1) 5VDC Power supply included Specifications Type: 4K HDMI Splitter Input Video Signal: 3.3V Input DDC Signal: 5Vp-p (TTL) Maximum Single Link Range: 4K*2K@30hz Deep Color: 48bit Video Formats Supported: High-speed HDMI, HDCP 1.4 Audio Formats Supported: LPCM, Dolby-AC3, DTS7.1, DSD Output Video: HDMI Resolutions Supported: 4K/1080p/1080i/720p/576p/576i/480p/480i Video Amplifier Bandwidth: 10.2Gbps Video Input Connector: 1x HDMI Type A 19-pin female Max. Input Cable Length: 24AWG: 50 (15m); 26AWG: 30 (10m); 28AWG: 16 (5m) Video Output Connector: 8x HDMI Type A 19-pin female Max. Output Cable Length: 24AWG: 50 (15m); 26AWG: 32 (10m); 28AWG: 16 (5m) Operating Voltage: 5VDC Power Supply: 2A@5VDC (2.1mm plug) ESD Protection: 8kV (air-gap discharge), 4kV (contact discharge) Current Draw: 1820mA@5VDC Operating Temperature: 32~104F (0~40C) Operating Humidity: 20~90% RH (no condensation) Dimensions: 4-7/16" x 10-3/16" x 1-1/4" (112 x 258 x 32 mm) Weight: 25.4-oz (720g)
