Description
- Digital Class-D Mono Block Amplifier
- Dual MOS-FET PWM Power Supply
- 1 Ohm Stable Load
- 12 dB/Octave - Variable Low Pass Filter
- 12 dB/Octave - Variable Subsonic Filter
- 4 Way Protection Circuit (Thermal, Voltage Speaker short and DC Offset)
- Wired Remote Control
SPECIFICATIONS: Input Sensitivity 6V Max 1500 x 1 @ 1 ohms RMS 800 x 1 @ 2 ohms RMS 450 x 1 @ 4 ohms RMS 1 OHM Stable Variable Low Pass Filter : 40HZ - 180HZ -12dB/8 Variable Crossover Slope (LPF) Signal / Noise Ratio : 92DB Operation Voltage : DC 10.5V - 15.5V Power Input Recommended Fuse : 140 Amps Dimensions : 12.48 L x 6.3 W x 2.75 H
