Taidacent

Taidacent Universal LVDS Controller Board 10-65 Inch LCD Screen HDMI DVI VGA to LVDS Driver Board DIY Notebook Display Kit (18.5-27 inch 1080P Universal 8 kit)

$ 105.79
Pseudo Checkbox Icon
Order within 0 hours and 0 minutes to get between -
Buying Bulk?
Delivery Truck IconTracked Shipping on All Orders Secure Payments
Headphones Icon 24/7 Customer SupportReturn Product Arrow Icon14-Day Returns
Description
  • CHIPSET: NT68676(UFG)
  • MARKET AREA :Asia-Pacific
  • OSD LANGUAGE: Simplified chinese, Traditional chIese, English, French, German, Italian, Spanish, Portuguese, Japanese, Korean (optional)
  • KEY FUNCTION : POWER, MENU, VOL+, VOL-, ADJUST/EXIT


CHIPSET:NT68676UFG
MARKET AREA :Asia-Pacific
OSD LANGUAGESimplified chineseTradtional chIeseEnglishFrenchGermanItalianSpanishPortugueseJapaneseKoreanoptional
PANEL
Panel Type :LED/LCD
Panel Interface:Single/Dual LVDS8bit
Max Resolution:20481152
PC-RGB:Format up to 20481152@60Hz
HDMI :480i480P576i ,576p,720p 1080i,1080p
AUDIO INPUT
PC Audio : Earphone input 0.2~2.0
AUDIO OUTPUT
Frequency Responses :100Hz15KHz @3dB(1KHz, OdB reference signal)
Max Output power:2x1W(8) THD+N<10%@1KHz (Power Supply:12V, Audio Input:0.5V)
POWER
Requirement:12V DC/12V(built)/12V,5V(built in)/12V,5V,5VSB(built in)
To Panel:3.3V/5V/12V
Management:Standby Power Consumption<0.5W(Board Only)
KEY FUNCTION :POWER, MENU, VOL+, VOL-, ADJUST/EXIT
